Specifications
Cooler Master MWE 80 + Gold 1050w Fully modular Power Supply (MPE-A501-AFCAG-WO) – ATX Version: ATX 12V V2.52, Input Voltage: 100-240V, Input Current: 13-6A, Input Frequency: 47-63Hz, Dimensions (L x W x H): 180 x 150 x 86 mm, Fan Size: 140mm, Fan Bearing: FDB, Fan Speed: 2200 RPM, Efficiency: ā„90% @ Typical Load, MTBF: >100,000 Hours, Connectors: 1 x ATX 24 Pin Connectors, 1 x EPS 4+4 Pin Connectors, 1 x EPS 8 Pin Connector, 12 x SATA Connectors, 4 x Peripheral 4 Pin Connectors, 6 x PCI-e 6+2 Pin Connectors, Series: MWE Gold Series, 80 Plus: Gold, Modular: Full Modular, Wattage: Above 750W
What's in the Box
Cooler Master MWE V2 1050W 80 + Gold Power Supply (MPE-A501-AFCAG-WO), Documentation
Warranty
10 Year Warranty
Model MPE-A501-AFCAG
ATX Version ATX 12V V2.52
PFC Active PFC
Input Voltage 100-240V
Input Current 13-6A
Input Frequency 47-63Hz
Dimensions (L x W x H) 180 x 150 x 86 mm
Fan Size 140mm
Fan Bearing FDB
Fan Speed 2200 RPM
Noise Level @ 20% 0 dBA
Noise Level @ 50% 14.9 dBA
Noise Level @ 100% 27.3 dBA
Efficiency ā„90% @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0-50Ā°C
Power Good Signal 100 - 150 ms
Hold Up Time >20ms at 100% Load
MTBF >100,000 Hours
Protections OVP, UVP, OPP, OTP, SCP, OCP
Regulatory TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4 Pin Connectors 4
PCI-e 6+2 Pin Connectors 6
Warranty 10 Years
Series MWE Gold Series
80 Plus Gold
Modular Full Modular
Wattage Above 750W
